Data Protection: Make a Wise Decision
Data Protection: Make a Wise Decision
It's not unusual for school district staff members to emulate Lewis Carroll's Mad Hatter, wearing six or eight hats simultaneously in their everyday efforts. Sometimes, the hat hardest to wear is IT management, which is important and challenging at the same time.
School districts operate on information; more importantly, available information. When that information is lost or access is interrupted, the impact can be felt among parents, students, faculty, and staff. The permanent loss of budgeting documents, student records, e-mail messages, or class registration data for thousands of students and employees would be catastrophic.
Potentially fatal data loss puts a priority on protecting and securing information. Smaller school districts are often at a disadvantage when trying to protect valuable business information, as they typically lack in IT budgets. Gartner estimates that less than half of all mid-size and only 25 percent of small organizations have disaster recovery plans in place.
Smaller schools face the same fundamental backup and data protection concerns as larger ones: What is the most cost-effective method to reliably protect and recover critical information? For many of these schools, the problem is even more difficult because they do not have ample IT staff to design, deploy and manage data storage backup and recovery systems.
The unanticipated loss of data is the reason to back up. The usual reasons considered for failure are earthquake, fire, and flood, but in fact the more likely reasons are hardware failure, software failure, viruses and worms, and human error/mishandling. Smaller organizations are more vulnerable to human error and sabotage, since equipment is often in an open office environment and is maintained by inexperienced and overloaded staff. If a disk drive fails, they could lose access to past registration and attendance files, grading documents, or essential accounting records.
The other essential question is: With all the material currently on disk, what should be backed up? The temptation would be to back up everything, whether it is a business record or not, but there is little business value in your aunt's photos from the Grand Canyon or your niece's breakup trauma. Backing up everything makes good sense, but your best efforts should focus on records that change.
A record is a document that contains the facts and relevant information your school utilizes in its day-to-day operations. Without records, you could not make many essential decisions and could not plan for the future in an organized and systematic manner.
Achieving backup goals
Like almost any event, data backup must be goal-oriented. Time and effort need to be invested in the planning and execution of backup. The three types of backup are full (which backs up all files regardless of whether they have changed); differential (which backs up all files modified since the last full backup); and incremental (which backs up only files that have changed since the last backup of any kind).
The first step is to identify and locate the files and folders to be included in a backup. Then, it is important to calculate the amount of storage space necessary to back up those files and folders, and possibly operating systems and application software.
Next, the IT manager must establish how large a backup window is available for executing the backup. Traditionally, backup was a "third shift" proposition where computer "dead time" was used for backup. But students, faculty, and staff have entered the world of 24/7 operation courtesy of the World Wide Web. Thanks to the Internet, records and inquiries can be serviced any time of the day or night. There is less and less time for backup, even in that third shift.
There are practical advantages to a short, speedy backup window. Availability is one: The faster the backup, the more duty cycles can be assigned to operational or transactional computing. Efficiency is another: It is possible to avoid idling staff unduly. Therefore, thoughtful planning for a rational backup window is important.
Finally, determine how the organization's business information grows; reflect on a one- and two-year cycle. This will help IT personnel select products that will scale over time, scalability being one sure way to keep up with data growth, which can be massive. The national averages vary between 25 percent and 50 percent growth per year, depending on the nature of the organization and the complexity of infrastructure.
With these basic questions answered, it is possible to work out a backup solution. The solution comes in two parts: the backup platform and the backup destination.
Selecting the backup software must involve the goals of capacity management, scalability, and speed discussed earlier. But there are other attributes that need to be discussed to make a sound backup decision.
Reliability is such an obvious attribute that it should go without saying. But solutions are a mixed bag, and the buyer needs to be aware of the degree to which the platform can be relied on.
Longevity is likewise an issue. The buyer must be certain that the solution will last over time. Some backups will not have to be accessed for some time, and the software platform will still need to operate. More importantly, technical support might be needed at some point in time. If the platform vendor is out of business, the organization might be in trouble.
Ease of use is going to be important both for the backup platform and the backup destination. In many settings, the person charged with the backup is not an IT professional. The responsible party might be an administrative employee, clerical staff, faculty, intern, or the department head who wears all the hats. Managing data can be complex, but the backup subsystem should be as simple as possible to save staff time and training expense.
Removability and portability are important elements of the backup destination. Whichever media is chosen, portability is important. Since backup is a disaster recovery (or business continuity) tool, the responsible party should be able to remove critical data from the main building location at some point, where earthquake, fire, flood, or even a human might take a toll. Whether it is stored in a bank vault or a financial officer's closet, portability creates an extra level of protection for that valuable information.
Cost is an issue, an assertion that comes as a surprise to nobody. In calculating cost, it is best to include the platform, the destination, the time spent in backup versus the time it would take to rebuild lost data in a data outage situation, staff time investment and any relevant overhead costs. But small and midsize organizations are the darlings of the computer storage industry right now, with storage vendors competing aggressively for their dollar like never before.
One of the advantages of current backup technology is that there is both the freedom and the burden of choice. But a careful examination of the different destination media will chart a course to the optimum SMB destination: removable disk.
The well known compact disc is an optical disc capable of storing data, although limited to a capacity of 650 MB to 850 MB. CD-ROM is a common format for software distribution. CD's first cousin, the DVD, is visible in the data storage market as well, and while the capacity is higher than that of the CD, it is still limited to between roughly 4.2 GB and 8.5 GB. They claim to offer long service life and a comparatively low cost. But capacities are more limited than most magnetic storage solutions, and I/O speeds may not fit in with the backup window. Additionally, CD media is fragile; scratching the surface loses data. DVD media is resistant to scratches, but is limited to a single level of error correction, casting a cloud on its reliability. And recordable CD and DVD media will degrade over time.
Tape has been the workhorse of backup for 50 years. Tape drives have data capacities of anywhere from a few hundred kilobytes to several gigabytes, and varying transfer speeds as well. While tapes are a very portable removable storage solution, the disadvantage of tape drives is that they are sequential-access devices, which means that to read any particular block of data, you need to read all the preceding blocks. The wait to restore essential files in a disaster recovery situation would be unacceptable to many schools, for whom fast restore time can be of the essence in keeping things going. This tape limitation is being recognized by OEMs, such as Dell, who are phasing out low end tape solutions with limited roadmaps (such as DDS) as part of their offerings.
Longevity of the media is also an issue: it is customary to relocate data to fresh tape every five years or so, and users often discover upon data recovery that the backup did not complete. Additionally, newer drives can be very costly, and might break the available budget.
Fixed disk is another potential option. It is familiar, high-speed, and not complex. But backup to another fixed disk is perilous. One fundamental challenge for hard disk technology is to prove its ability to provide cost effective offsite security, something of a hardship for a fixed-disk technology. As well, disk drives are less scalable: What is to be done when the capacity limit is hit? The alternative is to daisy chain one disk to another, which drags performance fiercely. Unlike tape and removable disk, fixed-disk technologies are not as portable as the alternatives and have to be handled carefully due to the drive mechanics being transported with the media. They are not built to be moved.
Schools need more than just one backup: It's best to set up a schedule using a regular rotation system. Don't just overwrite the backup with the next backup. Any kind of glitch or error in writing the new backup can leave no backup at all. Ideally, three removable cartridges should be put in rotation to ensure proper protection. One cartridge should be kept in the dock so that a backup can be performed at any time; a second cartridge containing a recent backup in the event of an emergency restore; and a third backup cartridge should be kept offsite.
Removable disk storage
Removable storage is not a new concept in the computer industry. Since the early 1980s, the industry has seen the standard floppy disk drive with the removable 3.5-inch diskettes. As computers and technologies have advanced over the years, removable storage technology has moved right along as well. Storage vendors can now offer reliable, cost-effective removable disk with capacities reaching from 40 GB to 160 GB.
Removable disks allow users to enjoy the economics of low cost, rugged media and the ability to preserve backup data away from the primary storage in a most simplistic and traditional backup process.
The most pervasive (available from several leading storage vendors) "disk to removable disk" storage line is based on ProStor Systems' (Boulder, CO) RDX technology. RDX technology is a 2.5-inch removable Serial ATA (SATA) hard drive that looks and acts like a tape cartridge, but performs with the speed and reliability of fixed disk. The media is remarkably robust, with a service life of 10 years and the ability to sustain a 3-foot drop onto concrete. The cartridge itself will alert the user that there is a problem either with the backup or the media so that when data recovery is performed, there are no surprises.
ProStor will refresh its cartridge capacities and speeds as new mobile hard drives are released from suppliers. (The company's technology reportedly works with any manufacturer's SATA drives.) RDX technology allows SMBs to upgrade to higher-capacity cartridges without having to buy new drives, preserving their technology investment and not requiring any forward migration of data.
As a random access medium, recovery from an RDX backup takes milliseconds, in contrast to a much longer serial search on a tape cartridge. File retrieval is in seconds rather than hours. It can be argued that ProStor Systems' RDX technology takes every positive aspect of both tape and disk and combines them into one versatile product. At the same time, RDX sheds the negative characteristics of each medium.
RDX drives interoperate with all leading backup software, and are available from Dell, Imation, and Tandberg Data (that recently completed the acquisition of Exabyte). RDX media from any manufacturer can be used with any RDX drive.
In a world where litigation is commonplace, regulations are endless, and interruption can mean extinction, smaller schools suffer as much or more vulnerability as larger ones. This makes the selection of the best backup tools even more crucial. The solution must scale over time, be simple to use and as easy on the budget as possible. Portability is a must for taking data off-site and securing it away from the workplace. And, rotating the media will provide a structured backup plan that provides maximum protection for the information. Implementing that structured plan with removable media provides an SMB solution that is easy, affordable, scalable and reliable. It could mean the difference between a managed solution and a trip through the Looking Glass to a Mad Tea Party.
- Buy the most reliable backup device and media: Your organization depends on it.
- Plan for the optimum high-speed backup window.
- Remember the need for fast, reliable restore.
- Find something that is scalable, easy to use and affordable.
- Take data offsite.
- Rotate media.
About the author: Mark Ferelli is an independent technology journalist, commentator and writer. He was formerly vice president of West World Production Inc. and Editor in Chief of their magazine group: Computer Technology Review, Storage Inc, Storage Management Solutions and Government, and Storage and Entertainment. Mark specializes in covering mass storage technologies and since 1988 has written hundreds of articles on the subject.
